PRESSURE BALANCED LUBRICATED PLUG VALVES API 6D & API 6A

Class 150 to 2500-Size:

D N 1/2” to 48”

API 2000 to API 10000

Psi-Size: DN 2 1/16” to 7 1/2”

Pressure balance lubricated plug valves are metal seated valves providing a tight shut off ( 0 leakage ) sealing, valves shall be regularly lubricated along with their operation by injection of suitable grease. Thanks to the absence of any body cavity and as well as a simple & tough design, they are highly recommended for any critical “Full ΔP” operation and for handling any media with an high % of solids contents, further more they provide an excellent resistance to abrasion, they are free from routine maintenance, providing a long service life.

Production Range:

API6D ASME/ANSI 150 up to 2500 Lb API6A from API 2000 up to API 15000 Available in SHORT, VENTURI or REGULAR Pattern.

DN 1/2” to 48” Class: up to 600

DN 1/2” to 36” Class: up to 900

DN 1/2” to 24” Class: up to 1500

DN 1/2” to 20” Class: up to 2500

DN 1 13/16” to 7 1/16” Class API 2000 to 15000 Psi

Operator:

Manual Gear or Wrench Operated; Electric Actuator, Pneumatic/Hydraulic actuator single or double acting; Gas Over Oil; Electro Hydraulic

PRESSURE BALANCED “FULL BORE” LUBRICATED PLUG VALVES API 6D & API 6A

PRESSURE BALANCED DB & B LUBRICATED PLUG VALVES API 6D & API 6A

LUBRICATED PLUG VALVES STANDARD TYPE API 6D - 2 WAYS, 3 & 4 WAYS MULTIPORT

DUAL SEAL PLUG VALVES DB&B API 6D

PTFE SLEEVED PLUG VALVES TWO WAY, TREE WAY AND FULLY JACKETED

Chemical Plants

Refinery

Letal Service

Sulfur Service

Fertilizer plant

Desalination Plant
